TS-14PFX-4 14 Channel Mixer with DSP with 4 group
TS-14PFX-4 14 Channel Mixer with DSP with 4 group
Couldn't load pickup availability
Feature:
* Professional compact mixer, ultra-low noise discrete microphone preamplifier and +48V phantom power, powerful functions and mellifluous sound quality.
* 8 channels of Mic input interface are compatible with 6 line input interfaces; microphone input interface supports 48V phantom power.
* 2 sets of stereo inputs and 4 channels of RCA inputs can be connected to stereo devices.
* Provide 2 sets of stereo main outputs, 4 marshalling outputs, 4 auxiliary outputs, 1 set of stereo monitoring output, 1 earphone monitoring output, 2 effect outputs.
* Provide 1 set of main mixing breakpoint insertion, 6 breakpoint insertion, and can be connected to additional processors (compressor, equalizer, limiter, etc.).
* 13 high-precision carbon film faders with 60mm stroke.
* Built-in MP3 player supports external U disk playback/recording through the USB interface.
* Built-in USB sound card can connect to computer for music playback and sound recording.
* Built-in 24-bit DSP audio processor can provide 100 preset effects.
* A USB power supply interface can be connected to USB light.
* Support 7-band graphic equalization fader adjustment.
* It has a dot matrix LCD screen with a resolution of 128*64, and users can view multimedia information such as Bluetooth, MP3, etc. through the display screen.
Specification:
|
Model |
TS-14PFX-4 |
|
Mic input |
8 channels (8 XLR interfaces) |
|
Line input |
6-channel single plug mono/stereo automatic switching hybrid interface |
|
Stereo input channel |
2 sets (4 channels of mono), 4 channels of RCA input |
|
Output channel |
2 stereo output, 4 group outputs, 4 auxiliary outputs, 1 headphone monitor output, 1 interface dual-channel effect output, 1 control room output |
|
INSERT |
1 set of main mix breakpoint insertion, 6 breakpoint insertion |
|
USB interface |
Playback and recording with a USB disk |
|
Wireless connection |
Built-in Bluetooth wireless transceiver, can be connected to a mobile phone to play music |
|
Audio processor |
24-bit DSP audio processor(including vocal, small house, hall, echo, echo + reverb, plate, vocal music board, chorus GTR, rotating GTR, vibrato GTR type), 100 preset effects |
|
USB sound card port |
Support computer recording/playback, playback through CH11/12 channel |
|
Phantom power |
Each channel of CH1-CH6 has 48V phantom switch independent control |
|
Frequency response |
20Hz-20kHz，±2dB |
|
Distortion |
<0.03% at+0dB,22Hz-22KHz A-weighted |
|
Sensitivity |
+20dB~-30dB |
|
SNR |
<-100dBr A-weighted |
|
Mono equalization |
High frequency: +/-15dB @12KHz; medium frequency: +/-15dB @100KHz-8KHz; low frequency: +/-15dB @80KHz |
|
Stereo equalization |
High frequency: +/-15dB @12KHz; medium frequency: +/-15dB @3KHz or +/-15dB @500KHz; low frequency: +/-15dB @80KHz |
|
Main mixing crosstalk |
<-80dB @0dB 20Hz-22KHz A-weighted, main output: 0dB, other channels: minimum |
|
Level meter |
2x12-dot pitch LED level indicator |
|
Supply voltage |
AC 100-240V 50/60Hz |
|
Rated power |
30W |
|
Dimension |
Product size (L×W×H) 441.1×441.9×94.3mm; display screen size 41.7×20.36mm |
|
Weight |
6.7Kg |
Download TS-14PFX-4 Datasheet
