TS-0300MS Conference System Server

Feature:

* Original clock synchronization and transmission technology, sampling rate 48K uncompressed audio transmission.

* Built-in high-performance DSP processor, with EQ, volume, delay and other adjustment functions.

* The audio input interface includes 1 RCA unbalanced input port and 1 XLR balanced input port. The audio output interface includes 1 RCA unbalanced output port and 1 XLR balanced output port.

* Adopt TCP/IP network protocol, support C/S and B/S architecture; it can be controlled by PC software or browser.

* Support the WEB control of audio matrix parameters (including EQ, volume, delay, microphone sensitivity, etc.), microphone status synchronization, Chinese, English, Russian and French switching, and the role separation controller.

* Large system capacity, the system supports a maximum of 300 wireless conference units. The maximum number of speakers in the system is 8 wireless microphones.

* Support Chinese, English, Russian, French and other languages.

* Through the PC software, you can view the information such as battery level, WiFi signal of the online wireless units; it supports one-key shutdown of all wireless units.

* With 1 POE network port, support power supply and data transmission for wireless AP.

* With a fire alarm linkage trigger interface, it provides fire alarm information to evacuate the venue personnel urgently.

* With 1 RS-485 interface, support up to 5 camera to realize camera tracking, support PELCO-D, VISCA camera control protocol; work with HD camera tracking server to realize automatic camera tracking.

* Four microphone management modes: FIFO (first in, first out), NORMAL (normal mode), VOICE (voice control mode), APPLY (application mode).

* Support functions such as meeting sign-in, voting, evaluation, and other custom functions.

* With a 2.2-inch full-color touch screen, it can realize parameter setting or viewing, and other touch operation.

* Powerful ID editing function, support ID coding for wired units, wireless units, interpreter machines, and role separation servers.

* Support 10-band EQ adjustment function; 2 LINEOUT output channels support 10-band EQ adjustment function.

* Support AP channel scanning, learn about the use of wireless channels on site, support automatic or manual configuration as the best channel, support online display of AP name list, convenient to check.

* Support connecting with speech transcription server to realize speech transcription function

* Support setting the master-slave dual backup function, when the master fails, it can automatically switch to the slave operation to realize double backup function.

* Support remote firmware upgrade through the web.
