Features:
* With 48KHz sampling rate is with the better sound quality than CD’s. There is DSP audio processing inside, there is no "pop" low-frequency impact sound.
* Advanced processing chip architecture, and unique processing algorithms, microphone boot connection time is only 5 seconds.
* With the function of intelligent detection of faults, it prompts the user for AP failure, host communication failure, signal is too weak etc.
* Support simple TYPE-C setting SSID, password function, ensure that the system will not connect to the wrong AP;
* With speech countdown and speech timekeeping function.
* With voice control, the microphone can be turned on intelligently. Adjusting the voice sensitivity and set the off time by the PC software.
* With 5-band EQ adjustment function (adjustable with PC software), you can adjust the overall sound effect of all microphone units to be perfect result.
* Support sign-in function, set and initiate sign-in through PC software.
* Adopt 128-bit AES encryption technology, support WPA/WPA2 wireless security technology, prevent eavesdropping and unauthorized access, provide higher confidentiality of the conference system.
* With wireless transmission technology, the venue can be carried out with very little time to conduct venue activities.
* The internal feedback suppression function can effectively prevent howling.
* Built-in lithium battery, battery capacity supports 15 hours of continuous speech.
* Built-in antenna to greatly improves WIFI network transmission efficiency.
* Support TYPE-C port for upgrade program and online charging.
Specifications:
Model |
TS-W302A |
Microphone type |
Cardioid directional electret microphone |
Frequency response |
80Hz~16KHz |
Microphone input impedance |
680Ω |
Sensitivity |
-41±1.5dB (0dB=1V/Pa,at 1KHz) |
Maximum SPL |
100dB(THD>3%) |
SNR |
>80dB(A) |
Crosstalk |
>70dB |
Dynamic range |
>80dB |
THD |
< 0.1% |
Maximum power consumption |
1W |
Power supply |
18650 lithium battery |
Charging method |
Connect the charging box through the TYPE-C interface |
Color |
Graphite grey |
Sign in function |
Touch the key to check in |
Display screen |
OLED screen |
Size (LxWxH) |
120*104*43mm |
Installation method |
Desktop |
Wireless frequency range |
5.15 GHz to 5.85 GHz |
Battery capacity |
4800mAh |
Weight |
0.6 Kg |
Speech mode working hours |
15 hours |
Mixed mode working time |
16 hours |
Mic rod length |
380mm (black) |
