Features:
High quality ceiling speaker, plastic basin frame, spring pressing system, convenient installation. It is suitable for hotels, clubs and so on.
Specification：
|
Rated power (100V) |
3W, 6W, 9W |
|
Rated power (70V) |
1.5W, 3W, 4.5W |
|
impedance |
Black: COM / Red: 3.3KΩ / Green: 1.7KΩ / White: 1.1KΩ |
|
Sensitivity (1W/1M) |
91dB |
|
Frequency response (-10dB) |
80-20kHz |
|
Speaker unit |
6"×1 |
|
Cutout size |
170mm |
|
Dimension |
200×86mm |
|
Weight |
0.9kg |
Download Datasheet for T-104U.
